Shanghai, China
About 10 PCS/Min
L/C, T/T, Western Union, Paypal, Money Gram
HT-900
Semi-Auto Wrapping
Good Paper or Transparent Film.
S Series Horizontal Winding Machine
About 6000-8000 PCS/Day
220V,50Hz
40-65mm
Handmade Soap, Toilet Soap, Laundry-Bar-Soap
120W
0.4-0.6MPa
2 Persons
60mm
60kg
750X800X1300mm
BSIT
Export Wooden Case
meet with GMP standards
Made in China
8422303090
75cm * 80cm * 130cm
60kg
Soap Wrapping Machine
Soap Pleat Wrapping Machine
Pneumatic
Beverage, Food, Medical, Chemical, Machinery, Commodity
Semi-Automatic
Fully Wrapped Winding Machine
HT-900 hotel manual soap pleat wrapping machine
Our machine advantage Feature :
1. By our HT900 hotel soap Pleated Wrapping machine working , the finished product with good-looking appearance
2.Instead of manual worker. Save both time and labour, increase of production , cost saving.
3. Simple operation and convenient maintenance
4. Use diameter range Max. Diameter 60mm,Max.thickness 35mm(It can adjust mould and screw under close disk.) it can customization mould
Soap packing sample:
Operate HT900 soap wrapping machine process step: Working video as reference: https://youtu.be/TY8BcR_hoAo
Worker lifts upper mould plate first , and put match packing material in suitable position, then lay down oscillating bar , taken together upper and under mould , lay down match soap . Open close disk , the close disk turn right until end , press soap head automatic press soap , closed the close disk after press soap head automatic back , then the close disk turn left and labeling. In the end, open the close disk , and remove finished soap after stepped on the foot switch.
optional device for manual labeling machine for HT900 soap pleat wrapping machine
Technical Parameter:
| Power supply | 220V50-60Hz |
| Power | 120W |
| Atmospheric pressure | 0.4-0.6MPa |
| Capacity | 6000-8000pcs/day |
| Operator | two persons |
| Max. Diameter 60mm(It can be adjusted by change mould) , Max.thickness 35mm(It can be finished by adjust screw under close disk. ) | |
| Weight | 60kg |
| Overall dimension | 750x800x1300mm |
