Shanghai, China
50 Sets/Year
L/C, T/T, Western Union, Paypal, Money Gram
YGG
Atmospheric Pressure
Pneumatic Lifting
Linear
Bottle
Plastic
80-100 Bottles/Min Per 10 Ml
Liquid
E-Cig Liquid, Eye-Drop, Oral Liquid
SS316 Contact with Product
Min. 20mm Max. 30mm
5-30ml
+-2%
220V 50/60Hz 1.5kw
50~70L/Min, 4~6bar
Length 2500, Width 1420, Height 1500
BSIT
Export Standard Wooden Case
meet with CGMP standards
Made in China
8422303090
Volumetric Filling Machine
Fully Automatic
Liquid
Multi-Head
Single-Room Feeding
Plunger
General Features:
E-Cig liquid, Eyedrop filling, plugging ∩ping machine for the application of round eyedrop bottle or similar ones, auto accomplish product filling, plug place, cap place, cap screw-on. The machine is composed by a load turntable, ceramic piston pump(alternative peristaltic pump) &fill nozzles, plug ∩ sorter, Plug ∩ placer, cap screw-on system, unload tray. The bottle loading/unloading is done manually, through loadingturntableØ500mm and unloading tray, or directly from an production line. It is designed and made accordance to GMP regulation.
1. BLP-120 automatic bottle Unscrambler
2. BYG4/2/2 E-cig Filling Plugging Capping Monobloc:
Technical Features:
| Kind of bottle | Round eyedrop bottle or similar |
| Bottle size | Min. Ø20mm Max. Ø30mm |
| Speed | 80~100bpm on 10ml~5ml |
| Filling volume | 5ml~30ml |
| Filling accuracy | ±2% |
| Power | 220V 50/60Hz 1.5kw |
| Compress air require | 50~70L/min, 4~6bar |
| Machine size mm | Length 2500, width 1420, height 1500 |
| Machine weight: | 900kgs |
General Features:
E-Cig liquid, Eyedrop filling, plugging ∩ping machine for the application of round eyedrop bottle or similar ones, auto accomplish product filling, plug place, cap place, cap screw-on. The machine is composed by a load turntable, ceramic piston pump(alternative peristaltic pump) &fill nozzles, plug ∩ sorter, Plug ∩ placer, cap screw-on system, unload tray. The bottle loading/unloading is done manually, through loadingturntableØ500mm and unloading tray, or directly from an production line. It is designed and made accordance to GMP regulation.
1. BLP-120 automatic bottle Unscrambler
2. BYG4/2/2 E-cig Filling Plugging Capping Monobloc:
Technical Features:
| Kind of bottle | Round eyedrop bottle or similar |
| Bottle size | Min. Ø20mm Max. Ø30mm |
| Speed | 80~100bpm on 10ml~5ml |
| Filling volume | 5ml~30ml |
| Filling accuracy | ±2% |
| Power | 220V 50/60Hz 1.5kw |
| Compress air require | 50~70L/min, 4~6bar |
| Machine size mm | Length 2500, width 1420, height 1500 |
| Machine weight: | 900kgs |
